1 pcs
Mininum order quantity from 1PCS 1812CA221KAT1A
Mininum order value from 1USD
2 days
lead time of 1812CA221KAT1A is from 2 to 5 days
12 hours
Fast quotation of 1812CA221KAT1A within 12 hours
60 days
60 days full quality warranty of 1812CA221KAT1A
1, we will give you new and original parts with factory sealed package
2, Quality warranted: All products have to be passed our Quality Control before delivery.
2,If you need more details of 1812CA221KAT1A,like pictures ,package,datasheet and so on, pls email to [email protected]
Capacitance Range 10 pF to 0.018 μF
(25°C, 1.0 ±0.2 Vrms at 1kHz, for ≤ 1000 pF use 1 MHz)
Capacitance Tolerances ±5%, ±10%, ±20%
Dissipation Factor 0.1% max. (+25°C, 1.0 ±0.2 Vrms, 1kHz, for ≤ 1000 pF use 1 MHz)
Operating Temperature Range -55°C to +125°C,1812CA221KAT1A AVX Corporation CAP CER 220PF 630V C0G/NP0 1812
Temperature Characteristic 0 ±30 ppm/°C (0 VDC)1812CA221KAT1A AVX Corporation CAP CER 220PF 630V C0G/NP0 1812
Voltage Ratings 600, 630, 1000, 1500, 2000, 2500, 3000, 4000 & 5000 VDC (+125°C)
Insulation Resistance (+25°C, at 500 VDC) 100K MΩ min. or 1000 MΩ - μF min., whichever is less
Insulation Resistance (+125°C, at 500 VDC) 10K MΩ min. or 100 MΩ - μF min., whichever is less
Dielectric Strength Minimum 120% rated voltage for 5 seconds at 50 mA max. current
Capacitance Range 10 pF to 0.33 μF (25°C, 1.0 ±0.2 Vrms at 1kHz)
Capacitance Tolerances ±10%; ±20%; +80%, -20% 1812CA221KAT1A AVX Corporation CAP CER 220PF 630V C0G/NP0 1812
Dissipation Factor 2.5% max. (+25°C, 1.0 ±0.2 Vrms, 1kHz)
Operating Temperature Range -55°C to +125°C
Temperature Characteristic ±15% (0 VDC) 1812CA221KAT1A AVX Corporation CAP CER 220PF 630V C0G/NP0 1812
Voltage Ratings 600, 630, 1000, 1500, 2000, 2500, 3000, 4000 & 5000 VDC (+125°C)
Insulation Resistance (+25°C, at 500 VDC) 100K MΩ min. or 1000 MΩ - μF min., whichever is less
Insulation Resistance (+125°C, at 500 VDC) 10K MΩ min. or 100 MΩ - μF min., whichever is less
Dielectric Strength Minimum 120% rated voltage for 5 seconds at 50 mA max. current
High Voltage MLC Chips FLEXITERM®
For 600V to 5000V Applications
